Product Description
The NEO 3.0 is a subwoofer built for SPL!! If you're looking for a SPL Championship proven subwoofer, here you go.
Custom Coil and Spider Configurations to get every tenth of a db out of it available.
Key Features
2024 Cone Change : Now Comes Stock with TR Cone / Surround
- Extremely rigid AR paper cone assembly
- Multilayered polymer foam surround
- Polypropylene dust cover with DC logo
- 8” OD semi cup progressive roll spiders
- Dual extra heavy duty interweaved tinsel lead wire
- Cast aluminum black frame
- FEA analyzed and optimized motor assembly – Fully CNC machined
- Rubber mounting gasket
- Chrome spring loaded push terminals
- 3" 8 layer hi-temp flat wound aluminum voice coil
ADD ON DESCRPTIONS:
: Carbon fiber cone: Black is thicker and more durable than stock pulp cones. Super SPL is even thicker and only used in extremely high SPL pressures.
:Nomex spiders: adds for a stiffer suspension SPL oriented sub.
: Extra spider: Makes the subwoofer have a stiffer suspension than stock.
:OFC 8 AWG direct lead option: Replaces terminals with OFC 8awg direct lead wire.
:SPL neck: Folded voice coil former & extra glue for extreme durability.
T/S Parameters
| 15" | 18" | |
|---|---|---|
| Mounting Depth | 9" | 11" |
| Mounting Hole Diameter | 14" | 16.75" |
| Outside Driver Diameter | 15.7" | 18.5" |
| VC Diameter | 3.0" | 3.0" |
| Displacement | .23ft | .26ft |
| Power Handling rms/peak | 2200/4400 | 2200/4400 |
| Ohm Options | d.7/d1/d2/d4 | d.7/d1/d2/d4 |
| Sd | 791 cm | 1159 cm |
| Vas | L | L |
| Cms | Mm/n | Mm/n |
| Mms | g | g |
| Fs | Hz | Hz |
| Bl | N/A | N/A |
| Re | Ohm | Ohm |
| Le | mH | mH |
| Qms | ||
| Qes | ||
| Qts | ||
| Xmax | 23mm | 23mm |
| Ref SPL @1 watt | db | db |
| Suggest Sealed Box | ft | ft |
| Suggested Ported Box | 3.0 ft | 5.5 ft |
